PCIe Gigabit Ethernet Fibre Network Interface Card with PoE+

1000Base-X and 10/100/1000Base-T PoE+

The N-GXE-POE-xx-01 is a type of network interface card (NIC) that connects to a secure fibre network and also provides power to a device like a VoIP phone through a copper cable. It works with the IEEE 802.3z and 1000Base-X standards, which allows it to transfer data quickly with speeds up to 2000 Mbps. This 2-port network card has 1 fibre port and 1 copper port that can provide power to devices through PoE+. The card is designed to combine both computer connectivity and phone connectivity into one device to save time and space. The card also helps to ensure high-quality phone calls by filtering and prioritizing VoIP traffic. Users can also customize VLANs and prioritization through software.

Download Datasheet
Request Quote
In August 2021, Transition Networks was acquired by Lantronix Inc. The products of Transition Networks will continue to be available from CoverTel as usual. Logo change of products from Transition Networks to Lantronix will be done progressively.
Category: Tag:

Interested in this product?

1800 268 378
This field is for validation purposes and should be left unchanged.

Description

The N-GXE-POE-xx-01 Series is a high-performance network interface card (NIC) that allows you to connect your computer to a secure fibre network and also provides power to devices like a VoIP phone. This card has two ports, one for the fibre network and one for the power and has a high speed connection of 2000 Mbps. It’s designed to make things easier for you by combining the functions of your computer and VoIP phone into one device, saving you time, money, and desk space. The card also has the ability to switch traffic between the ports even when your computer is in sleep mode. The card is set up to prioritize and filter VoIP traffic so you get a high quality connection. You can also adjust how the card handles traffic with the help of a software provided by Transition Networks.
The N-GXE-POE-xx-01 Series offers a bandwidth of 1000Mbps. It supports full-duplex mode, which enables communication in both directions simultaneously. The NIC is also compliant with the IEEE 802.3x Full-Duplex Flow Control standard, ensuring efficient data transfer. It has a PCIe x1 bus and is compliant with the PCIe Rev 2.1 Interface, providing fast and reliable connectivity. In addition, the NIC supports Jumbo Frames and has a high-level VLAN filtering function. It is also IPv6 capable, meaning it can support the latest internet protocol standard. Furthermore, the NIC supports IP headers and TCP/UDP checksum offload, making it easier for the system to process network traffic. The NIC also features Wake-on-LAN (WoL) power management, which enables it to be powered up remotely. Finally, it is PXE 2.1 Boot ROM supported and has an ACPI 2.0 Link Status LED for each port, making it easier to monitor network activity.
Key Features and Benefits:

  • High bandwidth 1000Mbps
  • Supports Full-duplex Mode
  • Supports IEEE 802.3x Full-Duplex Flow Control
  • Supports PCIe x1 bus
  • Compliant with PCIe Rev 2.1 Interface
  • Supports Jumbo Frames
  • Supports High Level VLAN Filtering Function
  • IPv6 Capable
  • Supports IP headers and TCP/UDP checksum offload
  • Wake-on-LAN (WoL) power management
  • PXE 2.1 Boot ROM Supported
  • ACPI 2.0 Link Status LED for each port
  • Driver Support
    • Windows 7
    • Windows 8, 8.1
    • Windows 10
    • Windows Server 2008
    • Windows Server 2012
    • Windows Vista
    • Linux
  • Available with a fixed LC port or an open SFP port
